Item
No.
Part Number Qty. Description Remarks
1 1016207 1 Manifold, Steer, Brake, Fan Includes 2 - 14, See Notes
2 121584 1 Cartridge, Relief Valve, Auto Balde Control
3 1016207-07 1 Cartridge, Compensator, Priority On Demand
4 1016207-08 1 Cartridge, Proportional Poppet, NC, Compensated
5 1016183-10 1 Super Coil, 5/8 ID, 12VDC Deutsch
6 750603 1
Cartridge, Relief Valve, Diff. Area
7 1016207-06 1 Cartridge, Unloading Pilot Relief
8 987322-16 1 Cartridge, Solenoid, 3W/2P
9 1001686-03 1 Coil, 12VDC Deutsch, J Series
10 1016207-09 1 Cartridge, 4W/2P Spool, Pressure Crossover
11 984357-06 1 Super Coil, 1/2 ID, 12VDC Deutsch
12 1016207-03 1 Cartridge, Check Valve
13 1016207-04 2 Cartridge, Check Valve, 3 PSI
14 1016207-01 3 Cartridge, Shuttle Valve
Hydraulic - Manifold, Brake/Steer/Fan - FA
NOTES:
1. Ensure the correct manifold manufacturer before ordering parts.
2. See Figure 6-40 for manifold schematic.
7
Illustrated Parts List (IPL)
Rosco CSV Variable Width Chip Spreader 7-37
