Item
No.
Part Number Qty. Description Remarks
1 1012620 1 Cooler, Electric Double Fan
REF 1012620-01 2 Assembly, Fan
2 1014307 1 Weldment, Mount, Cooler
3 1014634 1 Weldment, Cooler Cover
4 1013293 1 Weldment, Air Intake
5 1011301 1 Manifold, 3 Port -12
6 K811HT0606161616-238 1 Hose Assembly, Hydraulic Suction, 238” -16FJX/-16FJX
7
K811HT0639161616-98.5 1 Hose Assembly, Hydraulic, Suction, 98.5” 16FJX/-16FJX90S
8 100-6-16-16-5F 12
CSHH, 3/8-16 x 1.00, GR5, FT
9 302-6 12 Washer, Lock, 3/8
10 300-6 12 Washer, Flat, SAE, 3/8
11 100-4-20-12-5F 8
CSHH, 1/4-20 x .75, GR5, FT
12 302-4 8 Washer, Lock, 1/4
13 300-4 8 Washer, Flat, SAE, 1/4
14 100-5-18-52-5 2
CSHH, 5/16-18 x 3.25, GR5
15 300-5 4 Washer, Flat, SAE, 5/16
16 302-5 2 Washer, Lock, 5/16
17 200-5-18-5 2 Nut, Hex, 5/16-18, GR5
Hydraulic - Cooling System
7
Illustrated Parts List (IPL)
Rosco CSV Variable Width Chip Spreader 7-39
