Item
No.
Part Number Qty. Description Remarks
1 1014683 1 Panel, Fitting, Front
2 2700-8-8-LN 13 Adapter, Bulkhead Union, -8 JIC/-8 JIC
REF 205-12-10-5 13 Nut, Lock, Nylon, 3/4-10, GR5 Not Shown, See Note Below
3 1014684 1 Panel, Bulkhead, Front
4 1014492 1 Plate, Bulkhead
5 2700-16-16-LN 2 Adapter, Bulkhead Union, -16 JIC/-16 JIC
6 2700-6-6-LN 1 Adapter, Bulkhead Union, -6 JIC/-6 JIC
7 1014688 1 Panel, Bulkhead, Side
8 100-4-20-12-5F 16
CSHH, 1/4-20 x .75, GR5, FT
9 302-4 16 Washer, Lock, 1/4
10 300-4 16 Washer, Flat, SAE, 1/4
Hydraulic - External Connections
NOTE: The 3/4-10 Nylon Lock Nuts (Part # 205-12-10-5) are used to connect the union adapters
(Part # 2700-8-8-LN) to the front panel (1014683) rather than the brass nuts that are included
with the adapters.
7
Illustrated Parts List (IPL)
Rosco CSV Variable Width Chip Spreader 7-41
