Rear Hopper Wing - Right
Item
No.
Part Number Qty. Description Remarks
1 1016005 1 Weldment, Wing, Left
2 1016014 1 Plate, Wing
3 1016015 1 Hinge, Rubber
4 1016016 2 Bar, Hinge
5 1016013 1 Flashing, Wing
6 1013586 1 Weldment, Hinge
7 989495 2 Pin, Wing Included with Item 1
8 1013590 1 Weldment, Hinge
9 1012616 1 Cylinder, Hopper Wings
10 33964SRV 1 Switch, Backup Alarm, Neutral
11 100-6-16-24-5 12
CSHH, 3/8-16 x 1.50, GR5
12 300-6 24 Washer, Flat, SAE, 3/8
13 217-6-16 12 Nut, Lock, Flexloc, 3/8-16, Full, LT
14 105-8-13-28-F 5
CSFHS, 1/2-13 x 1.75, FT
15 300-8 5 Washer, Flat, SAE, 1/2
16 302-8 5 Washer, Lock, 1/2
17 200-8-13-5 5 Nut, Hex, 1/2-13, GR5
18 100-10-11-36-5 6
CSHH, 5/8-11 x 2.25, GR5
19 302-10 6 Washer, Lock, 5/8
20 300-10 6 Washer, Flat, SAE, 5/8
21 201-10-11-5 6 Nut, Hex, Heavy, 5/8-11, GR5
22 400-5-40 2
Roll Pin, 5/16 x 2.50 Included with Item 1
23 100-12-10-96-8 1 CSHH, 3/4-10 x 6.00, GR8
24 300-12 2 Washer, Flat, SAE, 3/4
25 217-12-10 2 Nut, Lock, Flexloc, 3/4-10, Full, LT
26 100-12-10-116-8 1
CSHH, 3/4-10 x 7.25, GR8
7
Illustrated Parts List (IPL)
Rosco CSV Variable Width Chip Spreader 7-47
