Item
No.
Part Number Qty. Description Remarks
1 1014439 1 Tube, Column
2 1003798 1 Valve, Steering, LS, 200 CCM
3 36128 1 Steering Column, 6.00 w/Wire
4 1014445 1 Weldment, Steering Face
5 1014624 1 Assembly, Cover, Steering
6 115772 1 Steering Wheel, 14”
7 112662 1 Horn Button
8 1014554 1 Cover, Column, Steering
9 1015166 1 Weldment, Cup Holder
10 1014485 1 Weldment, Extension, Column
11 1014581 1 Cover, Access Tube
12 1014558 1 Weldment, Cap
13 1015131 1 Chain, IGUS, Series 3480
14 1014470 1 Weldment, Pedal, Brake
15 853350 1 Valve, Brake w/Pedal, 1000 PSI
16 360010 1 Assembly, Seat, White w/Armrest
17 140600 1 Suspension Bracketry, Seat
18 207001201SRV 1 Weldment, Seat Base
19 100-6-16-20-5 7
CSHH, 3/8-16 x 1.25, GR5
20 302-6 A/R Washer, Lock, 3/8
21 300-6 A/R Washer, Flat, SAE, 3/8
22 105-4-20-12F A/R
CSFHS, 1/4-20 x .75, FT
23 100-6-16-18-5 4 CSHH, 3/8-16 x 1.125, GR5
24 122-4-20-12F 4 PHMS, Cross, 1/4-20 x .75, FT
25 100-4-20-12-5F A/R CSHH, 1/4-20 x .75, GR5, FT
26 302-4 A/R Washer, Lock, 1/4
27 300-4 A/R Washer, Flat, SAE, 1/4
28 100-6-16-24-5 3
CSHH, 3/8-16 x 1.50, GR5
29 100-8-13-20-5F 4 CSHH, 1/2-13 x 1.25, GR5, FT
30 302-8 4 Washer, Lock, 1/2
31 300-8 4 Washer, Flat, SAE, 1/2
32 100-6-16-16-5F 4
CSHH, 3/8-16 x 1.00, GR5, FT
33 200-6-16-5 7 Nut, Hex, 3/8-16, GR5
34 33687 1 Turn Signal w/Hazard, 7 Wire
Controls - Steering
7
Illustrated Parts List (IPL)
Rosco CSV Variable Width Chip Spreader 7-51
