7
Illustrated Parts List (IPL)
Rosco CSV Variable Width Chip Spreader 7-65
Item
No.
Part Number Qty. Description Remarks
GRP 1014628 Fuel Tank Assembly
1 1014629 1 Tank, Fuel
2 1015465 1 Cover
3 985688 1 Gasket, Hydraulic Tank, 20 Gallon
4 1015120 1 Sensor, Fuel
5 6806-8-8 NWO 1 Adapter, Elbow, 90°, -8 O-Ring/-8 NPTF
6 32874 2 Valve, Ball, 1/2 (Brass)
7 30182-8-6B 2 Fitting, Push-Lok, Brass, -8 MP/-6 PL
8 6401-8-8-O 1 Adapter, Straight, -8 O-Ring/-8 NPTF
9 1011971 1 Plug, Magnetic Drain, -16 SAE Orb
10 34231 1 Strainer, Fuel, In Filler Neck
11 34180 1 Cap, Fuel, 4.00 w/Chain
12 100-4-20-12-5F 12
CSHH, 1/4-20 x .75, GR5, 5F
13 302-4 12 Washer, Lock, 1/4
14 988581 12 Washer, 1/4 Weather Seal Bonded
15 129-#10-32-8 5 Machine Screw, Hex Head, #10-32 x .50
16 302-#10 5 Washer, Lock, #10
17 300-#10 5 Washer, Flat, SAE, #10
Tanks - Fuel
