Illustrated Parts List (IPL)
Rosco CSV Variable Width Chip Spreader 7-69
Item
No.
Part Number Qty. Description Remarks
1 1015669 2 Cover, Conveyor
2 1012801 1 Weldment, Mount DEF Tank
3 1012526-03 1 Tank, DEF
4 1012797 2 Strap, Hold Down, DEF Tank
5 1012641 1 Module, DEF, Supply
6 1014217 1 Bracket, Base, Filter
7 1014031 1 Filter, Return Hydraulic, 80 GPM
8 1014698 1 Weldment, Cover, Manifold
9 41591SRV 1 Weldment, Cover, Battery Box
10 007020097 4 Bracket, Anchor
11 007020096 4 Hook, Rubber
12 007020098 4 Bracket, Hood
13 100-5-18-36-5 4
CSHH, 5/16-18 x 2.25, GR5
14 300-5 A/R Washer, Flat, SAE, 5/16
15 302-5 A/R Washer, Lock, 5/16
16 200-5-18-5 4 Nut, Hex, 5/16-18, GR5
17 100-5-18-8-5F 4
CSHH, 5/16-18 x .50, GR5, FT
18 100-4-20-10-5F 12 CSHH, 1/4-20 x .625, GR5, FT
19 302-4 A/R Washer, Lock, 1/4
20 300-4 A/R Washer, Flat, SAE, 1/4
21 100-6-16-16-5F 8
CSHH, 3/8-16 x 1.00, GR5, FT
22 302-6 8 Washer, Lock, 3/8
23 300-6 8 Washer, Flat, SAE, 3/8
24 100-4-20-12-5F 4
CSHH, 1/4-20 x .75, GR5, FT
25 100-5-18-12-5F 4 CSHH, 5/16-18 x .75, GR5, FT
26 100-5-18-56-5 3 CSHH, 5/16-18 x 3.50, GR5
Panels and Covers - Left (1 of 4)
