Illustrated Parts List (IPL)
Rosco CSV Variable Width Chip Spreader 7-71
Item
No.
Part Number Qty. Description Remarks
GRP 1013507 Curtain Assembly - Left Includes 1-5
1 1013505 1 Curtain, Left
2 41584 1 Curtain Rod
3 41519 2 Handle
4 115-4-20-16 13 Screw, Self-Tapping, HWH, 1/4-20 x 1.00
5 308-4-16 9
Washer, Flat, Fender, 1/4 x 1.00
6 33265 2 Safety Hasp w/Swivel
7 81094 6
Rivet, Blind, AL, .188, .501 - .625
8 41516 1 Mount, Curtain, Upper
9 41515 1 Mount, Curtain, Lower
10 100-6-16-14-5F 4
CSHH, 3/8-16 x .875, GR5, FT
11 302-6 4 Washer, Lock, 3/8
Panels and Covers - Left (2 of 4)
