Illustrated Parts List (IPL)
Rosco CSV Variable Width Chip Spreader 7-93
Item
No.
Part Number Qty. Description Remarks
GRP 1014731 Front Chute Assembly
1 1014732 1 Weldment, Chute, Front
2 1013624 2 Leg, Chute (Front)
3 1013086 1 Weldment, Chute Door
4 1013099 1 Handle
5 1013100 1 Cam
6 1014735 1 Weldment, Deector, Chute
7 1014752 1 Plate, Wiper
8 1015439 1 Wiper, Rubber
9 1013625 1 Leg, Chute (Inside Rear)
REF 1013628 1 Leg, Chute (Outside Rear) Not Shown
10 3200DI 1 Water Tight Connection, 1/2 x 1/2 MPT
11 1014718 1 Pivot Cover
12 1014753 1 Pin, Pivot
13 1014715 1 Switch Mount
14 900135 1 Micro Switch, Auto, Augers
15 1014709 1 Pivot Paddle
16 102-4-20-20-F 1
CSSH, 1/4-20 x 1.50, FT
17 1014754 1 Roller, Adjustable
18 100-4-20-12-5F A/R
CSHH, 1/4-20 x .75, GR5, FT
19 302-4 A/R Washer, Lock, 1/4
20 300-4 A/R Washer, Flat, SAE, 1/4
21 100-6-16-16-5F 4
CSHH, 3/8-16 x 1.00, GR5, FT
22 302-6 10 Washer, Lock, 3/8
23 300-6 10 Washer, Flat, SAE, 3/8
24 100-4-20-8-5F 2
CSHH, 1/4-20 x .50, GR5, FT
25 100-6-16-24-5 6 CSHH, 3/8-16 x 1.50, GR5
26 102-#10-24-32-F 2 CSSH, #10-24 x 2.00, FT
27 302-#10 2 Washer, Lock, #10
Conveyors - Chute Assembly (Front)
