Illustrated Parts List (IPL)
Rosco CSV Variable Width Chip Spreader 7-95
Conveyors - Chute Assembly (Rear)
Item
No.
Part Number Qty. Description Remarks
GRP 1013082 Rear Chute Assembly
1 1013084 1 Weldment, Chute, Rear
2 1013624 2 Leg, Chute (Front)
3 1013086 1 Weldment, Chute Door
4 1013099 1 Handle
5 1013100 1 Cam
6 1013626 1 Leg, Chute (Outside Rear)
7 1014752 1 Plate, Wiper
8 1015439 1 Wiper, Rubber
9 1014718 1 Pivot Cover
10 3200DI 1 Water Tight Connection, 1/2 x 1/2 MPT
11 102-4-20-20-F 1
CSSH, 1/4-20 x 1.50, FT
12 1014754 1 Roller, Adjustable
13 900135 1 Micro Switch, Auto, Augers
14 1014715 1 Switch Mount
15 1014753 1 Pin, Pivot
16 1014709 1 Pivot Paddle
17 100-4-20-12-5F A/R
CSHH, 1/4-20 x .75, GR5, FT
18 302-4 A/R Washer, Lock, 1/4
19 300-4 A/R Washer, Flat, SAE, 1/4
20 100-4-20-8-5F 2
CSHH, 1/4-20 x .50, GR5, FT
21 100-6-16-24-5 6 CSHH, 3/8-16 x 1.50, GR5
22 302-6 6 Washer, Lock, 3/8
23 300-6 6 Washer, Flat, SAE, 3/8
24 102-#10-24-32-F 2
CSSH, #10-24 x 2.00, FT
25 302-#10 2 Washer, Lock, #10
To Next Page
