Illustrated Parts List (IPL)
Rosco CSV Variable Width Chip Spreader 7-105
Item
No.
Part Number Qty.* Description Remarks
1 1012849 1 Shield, Roll, Spread, LH
2 208712192 1
Bearing Assembly, 1.50 Bore, Step
3 1015267 1 Bearing, 1.50
4 1012854 1 Plate, Adapter
5 1012855 1 Collar
6 113-6-16-8 2 Set Screw, HSKT, Cup, 3/8-16 x .50
7 100-8-13-16-5F 4
CSHH, 1/2-13 x 1.00, GR5, FT
8 302-8 8 Washer, Lock, 1/2
9 300-8 8 Washer, Flat, SAE, 1/2
10 100-8-13-22-5 4
CSHH, 1/2-13 x 1.375, GR5
11 100-6-16-20-5 3 CSHH, 3/8-16 x 1.25, GR5
12 302-6 6 Washer, Lock, 3/8
13 200-6-16-5 6 Nut, Hex, 3/8-16, GR5
14 105-6-16-20-F 3
CSFHS, 3/8-16 x 1.25, FT
15 105-8-13-16-F 3 CSFHS, 1/2-13 x 1.00, FT
16 36688-17 2 Groomet, .250
Main Hopper - Drive Components (2 of 2)
*Quantities shown are for one hopper only
