7
Illustrated Parts List (IPL)
Rosco CSV Variable Width Chip Spreader 7-109
Item
No.
Part Number Qty.* Description Remarks
1 40858SRV 5 Weldment, Gate, 12”
2 1012844 8 Clevis
3 202-8-20-5 16 Nut, Hex, Jam, 1/2-20, GR5
4 1012843 8 Adapter, Cyclinder
5 72642 8
Cylinder, Hydraulic, 1.00 x 4.00 x .500 Rod
6 871075203 4 Collar, Set, 1.50 iD x 2.25 OD x 75 SST Includes Item 7
7 113-6-16-6 4 Set Screw, HSKT, Cup, 3/8-16 x .375
8 1012862 8 Weldment, Bracket, Cylinder
9 871081814 8
Roll Pin, 5/16 x 2.25
10 404-5-18 8 Pin, Clevis, 5/16 x 1.125
11 95923983 8 Cotter Pin
12 140610 11 Fitting, Lube, Straight, 1/4-28
13 40796SRV 8 Wear Bar, 12” Gate
14 114-6-16-36 8 Set Screw, SQHD, Cup, 3/8-16 x 2.25
15 200-6-16-5 A/R Nut, Hex, 3/8-16, GR5
16 106-6-16-16-5F A/R
Carriage Bolt, 3/8-16 x 1.00, GR5, FT
17 300-6 A/R Washer, Flat, SAE, 3/8
18 302-6 A/R Washer, Lock, 3/8
19 40857SRV 3 Weldment, Gate, 12” w/Pivot
REF 1013561 8 Assembly, Manifold, Gate Includes Items 20-23
20 1012785 8 Manifold, Individual Gate
21 6801-4-6 NWO 8 Adapter, Elbow, 90°, -4 JIC/-6 O-Ring
22 6400-4-6-0 8 Adapter, Straight, -4 JIC/-6 O-Ring
23 6801-4-6 NWO 16 Adapter, Elbow, 90°, -4 JIC/-6 JIC
24 1013560 1 Block, Mountingm Manifold
25 100-4-20-40-5 2
CSHH, 1/4-20 x 2.50, GR5
REF 100-4-20-32-5 14 CSHH, 1/4-20 x 2.00, GR5 Use on all other manifolds
26 300-4 19 Washer, Flat, SAE, 1/4
27 302-4 19 Washer, Lock, 1/4
28 200-4-20-5 2 Nut, Hex, 1/4-20, GR5
29 1012232 1 Switch, Diaphragm, Internal
30 1012863 1 Spacer, Sensor
31 1012864 1 Nipple, Pipe
32 99492 1
Pipe, Coupling, .500
33 3200DI 1 Water Tight Connector, 1/2 x 1/2 MPT
34 100-4-20-20-5 3
CSHH, 1/4-20 x 1.25, GR5
Main Hopper - Hydraulic Components (2 of 2)
*Quantities shown are for one hopper only
