Illustrated Parts List (IPL)
Rosco CSV Variable Width Chip Spreader 7-113
Option - Dual Operator - Control Console (2 of 4)
Item
No.
Part Number Qty. Description Remarks
GRP 1014503 Console Station Assembly, RH
1 1014502 1 Weldment, Console, Rosco CSV
2 1014413 1 Weldment, Column
3 1014427 2
Bearing, Sleeve, 1.5”
4 1014426 1 Pin, Pivot
5 410070 2 Bumper
6 1015526 1 Weldment, Joystick Box
7 1015525 1 Plate, Joystick
8 1015313-03 1 Decal, Operation, Control Panel - Right
9 1012525 1 Joystick, JS 6000, 5+1 Buttons
10 1015138 1 Cover
11 1014428 2 Bumper, 1”
12 1014730 1 Plate, Cover, Console Harness
13 1015156 1 Cover, Vandalism
14 1014841 1 Assembly, Mirror
15 129-#10-24-8 2 Machine Screw, Hex Head, #10-24 x .50
16 302-#10 2 Washer, Lock, #10
17 300-#10 2 Washer, Flat, SAE, #10
18 100-6-16-16-5F 1
CSHH, 3/8-16 x 1.00, GR5, FT
19 200-6-16-5 1 Nut, Hex, 3/8-16, GR5
20 122-4-20-8F 4
PHMS, Cross, 1/4-20 x .50, FT
21 302-4 A/R Washer, Lock, 1/4
22 300-4 A/R Washer, Flat, SAE, 1/4
23 100-5-18-12-5F 8
CSHH, 5/16-18 x .75, GR5, FT
24 302-5 6 Washer, Lock, 5/16
25 300-5 6 Washer, Flat, SAE, 5/16
26 100-6-16-20-5 4
CSHH, 3/8-16 x 1.25, GR5
27 302-6 4 Washer, Lock, 3/8
28 300-6 4 Washer, Flat, SAE, 3/8
29 100-4-20-12-5F 4
CSHH, 1/4-20 x .75, GR5, FT
30 102-4-20-12-F 2 CSSH, 1/4-20 x .75, FT
31 100-5-18-16-5F 2 CSHH, 5/16-18 x 1.00, GR5, FT
32 35812 1 Lock wOffset Cam
33 REF 1 Controls Console Panel
To Next Page
