Illustrated Parts List (IPL)
Rosco CSV Variable Width Chip Spreader 7-115
Item
No.
Part Number Qty. Description Remarks
1 1014823 1 Weldment, Plate, Console Panel
2 1011147 1 Receptacle, 12V Cigarette Lighter
3 1010657 1 Connector, 03-Pin, Panel Mount, Deutsch DT04-3P
4 1015313-02 1 Decal, Oper, Control Panel - Right
5 1012397 1 Switch, Rocker Can 4 Button - Left Auger Conveyor
6 1012946 1 Switch, Rocker Can 4 Button - Right Auger Conveyor
7 1010672 1 Switch, Emergency Stop, 1-NC
8 1012632 1 Switch, Rocker Can 5 Button
9 1012524 1 Display, DP 710 w/Video
10 1012398 1 Switch, Rocker Can 8 Button, Hopper Left
11 1012945 1 Switch, Rocker Can 8 Button, Hopper Right
12 122-4-20-12F 8
PHMS, Cross, 1/4-20 x .75, FT
13 300-4 8 Washer, Flat, SAE, 1/4
14 122-#6-32-12F 2
PHMS, Cross, #6-32 x .75, FT
15 300-#6 2 Washer, Flat, SAE, #6
16 122-#6-32-16F 4
PHMS, Cross, #6-32 x 1.00, FT
17 300-#8 4 Washer, Flat, SAE, #8
Option-Dual Operator - Console Panel (3 of 4)
To Next Page
