7
Illustrated Parts List (IPL)
Rosco CSV Variable Width Chip Spreader 7-117
Item
No.
Part Number Qty.* Description Remarks
1
1014472 1 Assembly, Floor - Right
2
1014551 1 Weldment, Ladder
3
1014513 1 Mount, Switch, Limit, Floor
4
1011853 1 Harness, Neutral Safety Tier 4
5
989567 1 Cylinder, Seat Slide Includes Items 6,7
6
989567-04 1 Pin, Clevis
7
989567-05 1 Cotter Pin
8
1014516 1 Weldment, Mount, Cylinder
9
1014352 1 Weldment, Handrail, Seat
10
1014514 1 Cover, Access, Switch
11
1014515 1 Cover, Access, Cylinder
REF 1014361 1 Weldment, Handrail Includes Items 12-14
12
1014362 1 Weldment, Handrail
13
1013354 1 Weldment, Handrail Pivot
14
1014511 1 Rod, Lock
15
100-6-16-16-5F 4 CSHH, 3/8-16 x 1.00, GR5, FT
16
302-6 12 Washer, Lock, 3/8
17
300-6 12 Washer, Flat, SAE, 3/8
18
100-6-16-20-5 4 CSHH, 3/8-16 x 1.25, GR5
19
100-8-20-24-5 1 CSHH, 1/2-20x 1.50, GR5
20
302-8 1 Washer, Lock, 1/2
21
300-8 1 Washer, Flat, SAE, 1/2
22
100-4-20-16-5F 6 CSHH, 1/4-20 x 1.00, GR5, FT
23
302-4 8 Washer, Lock, 1/4
24
300-4 8 Washer, Flat, SAE, 1/4
25
129-#10-24-8 2 Machine Screw, Hex Head, #10-24 x .50
26
302-#10 2 Washer, Lock, #10
27
300-#10 2 Washer, Flat, SAE, #10
Option - Dual Operator - Deck Extension (4 of 4)
To Next Page
