Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
95
Specifications and Reference Data
Code conformance
(18)
D 1-7
J2 ANSI/ASME B31.1 • •
J3 ANSI/ASME B31.3 • •
Material conformance
(19)
J5 NACE MR-0175/ISO 15156 • •
Country certification
J6 European Pressure Directive (PED) • • ★
J1 Canadian Registration • •
Installed in flanged pipe spool section
H3 150# Flanged connection with Rosemount standard length and schedule • •
H4 300# Flanged connection with Rosemount standard length and schedule • •
H5 600# Flanged connection with Rosemount standard length and schedule • •
Instrument connections for remote mount option
G2 Needle valves, Stainless Steel • • ★
G6 OS&Y gate valve, Stainless Steel • • ★
G1 Needle valves, Carbon Steel • •
G3 Needle valves, Alloy C-276 • •
G5 OS&Y gate valve, Carbon Steel • •
G7 OS&Y gate valve, Alloy C-276 • •
Special shipment
Y1 Mounting hardware shipped separately • • ★
Special dimensions
VM Variable mounting • •
VT Variable tip • •
VS Variable length spool section • •
Transmitter calibration certification
Q4 Calibration certificate for transmitter • • ★
QP Calibration Certificate & Tamper Evident Seal • • ★
Table 1. Rosemount 3051SFA Annubar Flowmeter Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
