Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
118
Specifications and Reference Data
Line size
200 20-in. (500 mm)
240 24-in. (600 mm)
300 30-in. (750 mm)
360 36-in. (900 mm)
420 42-in. (1066 mm)
480 48-in. (1210 mm)
600 60-in. (1520 mm)
720 72-in. (1820 mm)
780 78-in (1950 mm)
840 84-in. (2100 mm)
900 90-in. (2250 mm)
960 96-in (2400 mm)
Pipe I.D. range
(2)
C Range C from the Pipe I.D. table ★
D Range D from the Pipe I.D. table ★
A Range A from the Pipe I.D. table
B Range B from the Pipe I.D. table
E Range E from the Pipe I.D. table
Z Non-standard Pipe I.D. range or line sizes greater than 12-in. (300 mm)
Pipe material/Mounting assembly material
C Carbon steel (A105) ★
S 316 Stainless Steel ★
0 No Mounting (customer supplied) ★
G Chrome-Moly Grade F-11
N Chrome-Moly Grade F-22
J Chrome-Moly Grade F-91
Piping orientation
H Horizontal piping ★
D Vertical piping with downwards flow ★
U Vertical piping with upwards flow ★
Annubar type
P Pak-Lok ★
F Flanged with opposite side support ★
L Flange-Lok
Table 6. Rosemount 3051CFA Annubar Flowmeter Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
