Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
122
Specifications and Reference Data
Flow calibration
W1 Flow calibration (average K)
Special inspection
QC1 Visual and dimensional inspection with certificate ★
QC7 Inspection and performance certificate ★
Surface finish
RL Surface finish for low pipe Reynolds number in gas and steam ★
RH Surface finish for high Pipe Reynolds number in liquid ★
Material traceability certification
(12)
Q8 Material traceability certification per EN 10474:2004 3.1 ★
Code conformance
(13)
J2 ANSI/ASME B31.1
J3 ANSI/ASME B31.3
Materials conformance
(14)
J5 NACE MR-0175/ISO 15156
Country certification
J6 European Pressure Directive (PED) ★
J1 Canadian Registration
Installed in flanged pipe spool section
H3 150# Flanged connection with Rosemount standard length and schedule
H4 300# Flanged connection with Rosemount standard length and schedule
H5 600# Flanged connection with Rosemount standard length and schedule
Instrument connections for remote mount options
G2 Needle valves, Stainless Steel ★
G6 OS&Y gate valve, Stainless Steel ★
G1 Needle valves, Carbon Steel
G3 Needle valves, Alloy C-276
G5 OS&Y gate valve, Carbon Steel
G7 OS&Y gate valve, Alloy C-276
Special shipment
Y1 Mounting hardware shipped separately ★
Special dimensions
VM Variable mounting
Table 6. Rosemount 3051CFA Annubar Flowmeter Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
