Rosemount 3051SFC_A User Manual

Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
156
Specifications and Reference Data
Pipe I.D. range
(1)
C Range C from the Pipe I.D. table ★
D Range D from the Pipe I.D. table ★
A Range A from the Pipe I.D. table
B Range B from the Pipe I.D. table
E Range E from the Pipe I.D. table
Z Non-standard Pipe I.D. range or line sizes greater than 12-in. (300 mm)
Pipe material/Assembly material
C Carbon steel (A105) ★
S 316 Stainless Steel ★
0
(2)
No mounting (customer supplied) ★
G Chrome-Moly Grade F-11
N Chrome-Moly Grade F-22
J Chrome-Moly Grade F-91
Piping orientation
H Horizontal piping ★
D Vertical piping with downwards flow ★
U Vertical piping with upwards flow ★
Annubar type
P Pak-Lok ★
F Flanged with opposite side support ★
T
(3)
Threaded ★
L Flange-Lok
G Gear-Drive Flo-Tap
M Manual Flo-Tap
Sensor material
S 316 Stainless Steel ★
H Alloy C-276
Sensor size
1 Sensor size 1 — Line sizes 2-in. (50 mm) to 8-in. (200 mm) ★
2 Sensor size 2 — Line sizes 6-in. (150 mm) to 96-in. (2400 mm) ★
3 Sensor size 3 — Line sizes greater than 12-in. (300 mm) ★
Mounting type
T1 Compression/Threaded connection ★
A1 150# RF ANSI ★
Table 14. Rosemount 485 Annubar Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
