Rosemount 3051SFC_A User Manual

Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
163
Specifications and Reference Data
Annubar sensor type specification chart
RTD temperature limits
Integral and Remote Mounted Thermowell: -100 to 900 °F (-73 to 482 °C)
Instrument connections temperature ranges
Option code Description Pak-Lok
(1)
1. Available up to 600# ANSI (1440 psig at 100 °F [99 bar at 38 °C]) rating.
Flange-Lok Flange
Manual and
gear drive
Flo-Tap
T1
(1)
Pak-Lok Body X
Threaded connection X
A1 150# RF ANSI X X X
A3 300# RF ANSI X X X
A6 600# RF ANSI X X X
A9
(2)
2. Remote mount only.
900# RF ANSI X
AF
(2)
1500# RF ANSI X
AT
(2)
2500# RF ANSI X
D1 DN PN 16 X X X
D3 DN PN 40 X X X
D6 DN PN 100 X X X
R1 150# RTJ flange X X X
R3 300# RTJ flange X X X
R6 600# RTJ flange X X X
R9
(2)
900# RTJ flange X
RF
(2)
1500# RTJ flange X
RT
(2)
2500# RTJ flange X
Table 16. Minimum/Maximum Temperature Range
Code Description
Temperature
G1 Needle valves, Carbon Steel –20 to 500 °F (–29 to 260 °C)
G2 Needle valves, Stainless Steel –40 to 600 °F (–40 to 316 °C)
G3 Needle valves, Alloy C-276 –40 to 600 °F (–40 to 316 °C)
G5 OS&Y gate valve, Carbon Steel –20 to 775 °F (–29 to 413 °C)
G6 OS&Y gate valve, Stainless Steel –40 to 850 °F (–40 to 454 °C)
G7 OS&Y gate valve, Alloy C-276 –40 to 1250 °F (–40 to 677 °C)
A Integral needle valves, Stainless Steel, Remote-mount NPT connections –20 to 450 °F (–29 to 232 °C)
B Integral needle valves, Stainless Steel, Remote-mount SW connections –20 to 450 °F (–29 to 232 °C)
