Specifications and Reference Data
Opposite side support
C
(9)
NPT Threaded opposite support assembly ★
D
(3)
Welded opposite support assembly ★
E Flanged opposite support assembly
0
(2)
No opposite side support required
Packing gland
0
(1)
Not Applicable ★
L
(2)
SS packing gland/Graphite packing
T
(3)
Main steam packing gland/Graphite packing
Insertion mechanism
0
(1)(3)
Not applicable ★
C Alloy Steel insertion rods/nuts
S Stainless Steel insertion rods/nuts
Isolation valve
0
(1)(3)
Not applicable or customer supplied ★
1 Gate valve, Carbon Steel
2 Gate valve, Stainless Steel
5 Ball valve, Carbon Steel
6 Ball valve, Stainless Steel
Temperature measurement
0 No temperature sensor required ★
R
(4)(6)(9)
Remote RTD (
1
/2-in. NPT Aluminum housing) with thermowell
S
(4)(6)(9)
Remote RTD (
1
/2-in. NPT Stainless housing) with thermowell
Transmitter connection platform
3
(6)(10)(11)
Direct-Mount, 3-valve Manifold ★
4
(6)(10)(11)
Direct-Mount, Dual 3-valve Manifolds
6
(6)(10)(12)
High Temperature Direct-Mount 5-valve Manifold
7 Remote-Mount
1
/2-in. threaded connections
8
(3)
Remote-Mount
1
/2-in. welded connections
Mounting flange bolting materials
A 193 Gr B7 studs with A194 Gr 2H nuts ★
0 No flange studs/nuts supplied ★
Mounting flange gasket materials
1 Spiral wound, 304SS, Flexible-Graphite filler ★
Table 19. Rosemount 585 Annubar Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
