Rosemount 3051SFC_A User Manual

Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
198
Specifications and Reference Data
2 2 – 300# 4.38 (111.3) 12.00 (304.8)
19.03
(483.4)
9.00 (228.6) 6.86 (174.2) 5.00 (127.0)
2 2 – 600# 4.75 (120.7) 12.00 (304.8)
19.03
(483.4)
9.00 (228.6) 6.86 (174.2) 5.00 (127.0)
2 DN50/PN16 3.40 (86.4) 12.00 (304.8)
19.03
(483.4)
9.00 (228.6) 6.30 (160.0) 5.00 (127.0)
2 DN50/PN40 3.52 (89.4) 12.00 (304.8)
19.03
(483.4)
9.00 (228.6) 6.86 (174.2) 5.00 (127.0)
2 DN50/ PN100 4.30 (109.2) 12.00 (304.8)
19.03
(483.4)
9.00 (228.6) 6.86 (174.2) 5.00 (127.0)
2 2 – 900# 5.88 (149.4) 10.50 (266.7) N/A N/A N/A 5.00 (127.0)
2 2 – 1500# 5.88 (149.4) 10.50 (266.7) N/A N/A N/A 5.00 (127.0)
2 2 – 2500# 9.88 (251.0) 15.63 (397.0) N/A N/A N/A 4.50 (114.3)
3 3 – 150# 4.63 (117.6) 13.50 (342.9)
20.53
(521.5)
9.00 (228.6) 6.30 (160.0) 4.00 (101.6)
3 3 – 300# 5.00 (127.0) 13.50 (342.9)
20.53
(521.5)
9.00 (228.6) 6.86 (174.2) 4.00 (101.6)
3 3 – 600# 5.38 (136.7) 13.50 (342.9)
20.53
(521.5)
9.00 (228.6) 6.86 (174.2) 4.00 (101.6)
3 DN80/PN16 3.85 (97.8) 13.50 (342.9)
20.53
(521.5)
9.00 (228.6) 6.30 (160.0) 4.00 (101.6)
3 DN80/PN40 4.16 (105.7) 13.50 (342.9)
20.53
(521.5)
9.00 (228.6) 6.86 (174.2) 4.00 (101.6)
3 DN80/ PN100 4.95 (125.7) 13.50 (342.9)
20.53
(521.5)
9.00 (228.6) 6.86 (174.2) 4.00 (101.6)
3 3 – 900# 8.19 (208.0) 13.06 (331.7) N/A N/A N/A 7.00 (177.8)
3 3 – 1500# 8.56 (217.4) 13.81 (350.8) N/A N/A N/A 7.00 (177.8)
3 3 – 2500# 11.19 (284.2) 17.31 (439.7) N/A N/A N/A 7.00 (177.8)
Dimensions are in inches (millimeters).
Table 44. Flanged Annubar Flowmeter Dimensional Data
Sensor
size
Flange size and
rating
A ± 0.125
(3.2)
B ± 0.25
(6.4)
C ± 0.25
(6.4)
D (Max) E (Max) F (Max)
