Rosemount 3051SFC_A User Manual

Reference Manual
00809-0100-4809, Rev DA
Appendix B: Product Certifications
September 2015
223
Product Certifications
3. Intrinsically Safe parameters:
Note 1: FISCO parameters apply to both Group IIC and
IIB.
Note 2: [For Flowmeters] When 644 temperature
transmitter is used, the 644 temperature transmitter
should be used with Ex-certified associated apparatus to
establish explosion protection system that can be used
in explosive gas atmospheres. Wiring and terminals
should comply with the instruction manual of both 644
temperature transmitter and associated apparatus. The
cables between 644 temperatures transmitter and
associated apparatus should be shielded cables (the
cables must have insulated shield). The shielded cable
has to be grounded reliably in a non-hazardous area.
4. Transmitters comply with the requirements for FISCO
field devices specified in IEC60079-27:2008. For the
connection of an intrinsically safe circuit in accordance
with FISCO Model, FISCO parameters are listed in the
table above.
5. The product should be used with Ex-certified associated
apparatus to establish explosion protection system that
can be used in explosive gas atmospheres. Wiring and
terminals should comply with the instruction manual of
the product and associated apparatus.
6. The cables between this product and associated
apparatus should be shielded cables (the cables must
have insulated shield). The shielded cable has to be
grounded reliably in a non-hazardous area.
7. End users are not permitted to change any intern
components but to settle the problem in conjunction
with the manufacturer to avoid damage to the product.
8. During installation, use and maintenance of this
product, observe the following standards:
GB3836.13-1997, GB3836.15-2000, GB3836.16-2006,
GB50257-1996, GB12476.2-2006, GB15577-2007
N3 China Type n
Certificate: GYJ15.1105X
Standards: GB3836.1-2010, GB3836.8-2003
Markings: Ex nA nL IIC T5 Gc (-40 °C 
 T
a
 +70 °C)
Special Condition for Safe Use (X):
1. Symbol “X” is used to denote specific conditions of use:
The apparatus is not capable of withstanding the 500V
test to earth for one minute. The must be taken into
consideration during installation.
Japan
E4 Japan Flameproof
Certificate: TC20577, TC20578, TC20583, TC20584
[HART]; TC20579, TC20580, TC20581,
TC20582 [Fieldbus]
Markings: Ex d IIC T5
Technical Regulations Customs Union (EAC)
EM EAC Flameproof
Certificate: RU C-US.Gb05.B.00400
Markings: Ga/Gb Ex d IIC T5/T6 X,
T5(-60 °C 
 T
a
+80 °C),
T6(-60 °C   T
a
+65 °C)
Special Condition for Safe Use (X):
1. See certificate for special conditions
IM EAC Intrinsically Safe
Certificate: RU C-US.Gb05.B.00400
Markings: HART: 0Ex ia IIC T4/T5 Ga X,
T4(-60 °C 
 T
a
 +70 °C),
T5(-60 °C 
 T
a
+40 °C)
Fieldbus/PROFIBUS: 0Ex ia IIC T4 Ga X
(-60 °C   T
a
+60 °C)
Special Condition for Safe Use (X):
1. See certificate for special conditions
Combinations
K2 Combination of E2 and I2
K5 Combination of E5 and I5
K6 Combination of C6, E8, and I1
K7 Combination of E7, I7, and N7
K8 Combination of E8, I1, and N1
KB Combination of E5, I5, and C6
KD Combination of E8, I1, E5, I5, and C6
KM Combination EM and IM
Conduit Plugs and Adapters
IECEx Flameproof and Increased Safety
Certificate: IECEx FMG 13.0032X
Standards: IEC60079-0:2011, IEC60079-1:2007,
IEC60079-7:2006-2007
Markings: Ex de IIC Gb
ATEX Flameproof and Increased Safety
Certificate: FM13ATEX0076X
Standards: EN60079-0:2012, EN60079-1:2007,
IEC60079-7:2007
Markings: II 2 G Ex de IIC Gb
Parameters
HART
Fieldbus/
PROFIBUS
FISCO
Voltage U
i
30 V 30 V 17.5 V
Current I
i
200 mA 300 mA 380 mA
Power P
i
0.9 W 1.3 W 5.32 W
Capacitance C
i
0.012 F 0 F < 5 nF
Inductance L
i
0 mH 0 mH < 10 F
