Rotax 912 i series - Engine Management ECU

BRP-Rotax
MAINTENANCE MANUAL LINE
ENGINE MANAGEMENT ECU
Safety notice
m WARNING
Non-compliance can result in serious injuries or death!
When working on the ECU, the general safety instruction must be observed. See chap-
ter „INTRO“.
Figure 7.4: Engine management ECU
1 ECU 2 Rubber isolator
3 Socket for APM-connector
Effectivity: 912 i Series
Edition 2/Rev. 0
12–20–00
Page 11
September 01/2018
