Rotax 912 i series Service Manual

BRP-Rotax
MAINTENANCE MANUAL LINE
EXCEEDING OF MAX. COOLANT TEMPERATURE
General note
ATTENTION
If the maximum coolant temperature is exceeded, other limits are also often ex-
ceeded, e.g. oil temperature. Please observe the relevant instructions.
NOTE
Any exceeding of the max. admissible coolant temperature must be entered by
the pilot into the engine log book, stating duration, extent of excess temperature
and pertinent detail.
Proceed as instructed
in table 2
Proceed as
instructed in table 1
30 min.
135°C
(275 °F)
Operating limit
(See Operators Manual 912 i Series)
0 Time
Figure 5.12: Overview and proceed:
Temperature exceeded briefly
05–50–00
Page 20
September 01/2018
Effectivity: 912 i Series
Edition 2/Rev. 0

Rotax 912 i series Specifications

General

Number of Cylinders	4
Max Power	100 hp (73.5 kW)
Max Power Output RPM	5800 rpm
Ignition System	Dual electronic ignition
Oil System	Dry sump, forced lubrication with separate oil tank
Reduction Gear Ratio	2.43:1
TBO	2000 hours
Engine Type	4-stroke, horizontally opposed
Displacement	1352 cm³
Bore x Stroke	84 mm x 61 mm
Max Torque	128 Nm
Fuel Type	Avgas 100LL or unleaded automotive gasoline
Fuel System	Electronic fuel injection
Cooling System	Liquid/air-cooled
