Rotax 912 i series Service Manual

BRP-Rotax
MAINTENANCE MANUAL LINE
OIL PRESSURE BELOW MINIMUM VALUE
General note
ATTENTION
If the oil pressure falls below the minimum value, other limits are often exceeded,
e.g. the oil temperature. Please observe the relevant instructions.
NOTE
Any exceeding of the min. admissible oil pressure must be entered by the pilot in-
to the engine log book, stating duration extent of excessive pressure and pertinent
details.
0.5 bar
(7.3 psi)
Operating limit
(See Operators Manual 912 i Series)
Proceed as instructed
in table 6
Proceed as instructed
in table 5
0
1 min. Time
Figure 5.14: Overview and instruction
Oil pressure below minimum oil pressure on the ground
If noticed on ground, immediately stop the engine and determine the cause.
• Inspect the complete lubrication system, trace cause and rectify.
See Service Instruction SI-912-005, latest issue.
Effectivity: 912 i Series
Edition 2/Rev. 0
05–50–00
Page 25
September 01/2018

Rotax 912 i series Specifications

General

Number of Cylinders	4
Max Power	100 hp (73.5 kW)
Max Power Output RPM	5800 rpm
Ignition System	Dual electronic ignition
Oil System	Dry sump, forced lubrication with separate oil tank
Reduction Gear Ratio	2.43:1
TBO	2000 hours
Engine Type	4-stroke, horizontally opposed
Displacement	1352 cm³
Bore x Stroke	84 mm x 61 mm
Max Torque	128 Nm
Fuel Type	Avgas 100LL or unleaded automotive gasoline
Fuel System	Electronic fuel injection
Cooling System	Liquid/air-cooled
