Rotax 912 i series Service Manual

BRP-Rotax
MAINTENANCE MANUAL LINE
OVERFLOW BOTTLE
General note
Figure 7.16: Overflow bottle
1
Venting bore
2
Tab for the safety wire
3 Hose connection
Instruction Checking overflow bottle.
Step
Procedure
1
Inspect the bottle for damage.
2
Check the venting bore (1) in the screw cap.
3 Inspect tab (2) for the safety wire.
4
Check hose connection (3).
ACCESSORIES (INCLUDING RADIATOR, RADIATOR HOSES, HOSE CLAMPS,
COOLING AIR DUCTS)
General note Accessories (including radiator, radiator hoses, hose clamps, cooling air ducts)
ATTENTION
Equipment is to be inspected in accordance with the Maintenance Manual of the
aircraft manufacturer.
12–20–00
Page 28
September 01/2018
Effectivity: 912 i Series
Edition 2/Rev. 0

Rotax 912 i series Specifications

General

Number of Cylinders	4
Max Power	100 hp (73.5 kW)
Max Power Output RPM	5800 rpm
Ignition System	Dual electronic ignition
Oil System	Dry sump, forced lubrication with separate oil tank
Reduction Gear Ratio	2.43:1
TBO	2000 hours
Engine Type	4-stroke, horizontally opposed
Displacement	1352 cm³
Bore x Stroke	84 mm x 61 mm
Max Torque	128 Nm
Fuel Type	Avgas 100LL or unleaded automotive gasoline
Fuel System	Electronic fuel injection
Cooling System	Liquid/air-cooled
