BRP-Rotax
MAINTENANCE MANUAL LINE
Figure 7.25: Overview TYPICAL
INSTALLATION OF THE MAGNETIC PLUG
Install The following steps are necessary:
Step
Procedure
1 Clean the magnetic plug.
2
Install the magnetic plug. Tightening torque 25 Nm (18 ft lb.)
3
Secure with safety wire.
Inspect all systems for correct function. Detailed inspection of affected engine
components.
Effectivity: 912 i Series
Edition 2/Rev. 0
12–20–00
Page 45
September 01/2018
