Rotax 912 i series - Differential pressure check

BRP-Rotax
MAINTENANCE MANUAL LINE
DIFFERENTIAL PRESSURE CHECK
General note
m WARNING
Risk of electric shock!
Ignition “OFF” and system grounded!
Figure 7.2: Differential pressure check. TYPICAL
1
Adaptor
2
Manometer/Test gauges set
3
Orifice jet
4
Compressor
Effectivity: 912 i Series
Edition 2/Rev. 0
12–20–00
Page 7
September 01/2018
