Rotax 912 i series Service Manual

BRP-Rotax
MAINTENANCE MANUAL LINE
Cleaning To clean the dry filter the following steps are necessary:
Step
Procedure
1
Lightly tap and brush off surface dirt (A).
2 Spray K&N filter cleaner onto filter surface and leave to soak for approx. 10
min. (B).
3
Rinse air filter with low pressure water from inside to outside and let ele-
ment dry naturally (C).
08864
A B C
Figure 7.10: Cleaning the dry air filter
After cleaning
ATTENTION
Never use gear oil, diesel or engine oil, as they attract humidity.
NOTE
Each filter pleat must be sprayed with oil.
After 5 to 10 min. the filter will be soaked with oil, noticeable by the uniform red coloring.
08865
A
I
R
F
I
L
T
E
R
O
I
L
Figure 7.11: After cleaning
Effectivity: 912 i Series
Edition 2/Rev. 0
12–20–00
Page 21
September 01/2018

Rotax 912 i series Specifications

General

Number of Cylinders	4
Max Power	100 hp (73.5 kW)
Max Power Output RPM	5800 rpm
Ignition System	Dual electronic ignition
Oil System	Dry sump, forced lubrication with separate oil tank
Reduction Gear Ratio	2.43:1
TBO	2000 hours
Engine Type	4-stroke, horizontally opposed
Displacement	1352 cm³
Bore x Stroke	84 mm x 61 mm
Max Torque	128 Nm
Fuel Type	Avgas 100LL or unleaded automotive gasoline
Fuel System	Electronic fuel injection
Cooling System	Liquid/air-cooled
