BRP-Rotax
MAINTENANCE MANUAL LINE
Spark plug face Spark plug face reveals the following about the operating condition of the engine:
Spark plug face Information
light tan- coloured
plug and calibration of the engine are correct
velvet black
Possibly indicates one or more of the following:
mixture too rich
insufficient air intake (clogged air filter)
engine operating temperature too low
oily, glossy coating
Possibly indicates one or more of the following:
damaged valve stem seal
misfiring
too much oil in combustion chamber
worn cylinder and piston rings
white with formation
of melt beads
Possibly indicates one or more of the following:
mixture too lean
leaking valves
Effectivity: 912 i Series
Edition 2/Rev. 0
12–20–00
Page 49
September 01/2018
