BRP-Rotax
Maintenance Manual
72-00-00
page 46
July 01/2008
Effectivity 912/914 Series
Edition 1 / Rev. 2
d04351
Fig. 72-46
Magn.: approx. 75%
00150
Fig. 72-45
Magn.: approx. 75%
00149
00148
Fig. 72-44
Magn.: approx. 100%
◆ NOTE: Because of the small size of the pitting shown and the
copying process, the pictures may not show the pitting
clearly enough. If you are in any doubt, seek assistance
by studying technical publications or consult your au-
thorized ROTAX distributor or Service Center.
