Rotax MMH-912 Series User Manual

76-00-00
page 56
July 01/2008
Effectivity 914 Series
Edition 1 / Rev. 2
d04355
BRP-Rotax
Maintenance Manual
Fit the push lines onto the 3-way solenoid valve and secure
with clamp (6).
Position push lines and adapter cable (2) and secure with clamps
(6).
■■
■■
■ CAUTION: Always obey the additional instruction.
07231
Variant 2
07232
1
12
12
13
14
6
8
12
9
10
12
7
2
13
Fig. 76-51
