Effectivity 914 Series
Edition 1 / Rev. 2
76-00-00
page 55
July 01/2008
d04355
BRP-Rotax
Maintenance Manual
Variant 2 for airbox part no. 867753
(attachment of the 3-way solenoid valve on the engine
suspension frame)
parts requirement:
Fig New Qty/ Description Old Application
No. part no. engine part no.
- 881040* 1 retrofit kit - airbox
7 n.a** 1 bracket - 3-way solenoid valve
8 241841 2 allen screw M5x12 - bracket
9 927571 2 washer 5,3 - bracket
10 842030 2 lock nut M5 - bracket
* following parts of the retrofit kit are not necessary for Variant 2:
2x bracket (3), 2x allen screw M6x14 (4), 2x lock nut M6 (5)
** not yet available.
Disassembly and assembly - Variant 2
Remove connection wiring harness (11) of 3-way solenoid
valve (1).
Cut off tie wraps (6).
Loosen 3x clamps (12) from 3-way solenoid valve and remove
lines.
Loosen clamps (13) from engine suspension frame (14) and
remove 3-way solenoid valve.
Connect adapter cable (2) to wiring harness.
Tighten the new 3-way solenoid valve with allen screw (8),
washer (9) and lock nut (10) onto bracket (7). Tightening
torque 8 Nm (70 in. lb).
Install 3-way solenoid valve with clamp (13) onto engine
suspension frame.
■■
■■
■ CAUTION: Route all pressure connections such that there
will be no sharp bends or chafing.
