EbV Product documentation THETA NORM/UNIT
8-58
8.13 Global Malfunction Message Output
NOTE: This function must be activated in the HYDRAULIC level for a variable output (VO1
or VO2).
Function: The function is activated during errors and serves as a common global malfunction
message output for the connection of optical or acoustic signals.
8.14 Global Malfunction Message Input
NOTE: This function must be activated in the HYDRAULIC level for a variable input (VI1 to
VI3).
Funktion: When this function is activated, the corresponding input acts as a contact. If the
contact is closed (shorted), the global malfunction message input is treated as an
extra error in the control circuit. Activated malfunction messages can be transferred
to the data bus or can be registered via a global malfunction message output.
Up to 3 different malfunction message inputs can be used via variable inputs.
8.15 Timer
NOTE: Only active if setting "timer" was selected in the "HYDRAULIC" level for the HC-P
output.
Function: The function controls a consumer according to the current switching time program of
the unmixed circuit.
Operation:
Note on operation Key / parameter tree Parameter
Activation global malfunction
message output
HYDRAULIC PARAMETER 05
or
PARAMETER 06
or
PARAMETER 07
Operation:
Note on operation Key / parameter tree Parameter
Activation global malfunction
message input
HYDRAULIC PARAMETER 08
or
PARAMETER 09
or
PARAMETER 10
Operation:
Note on operation Key / parameter tree Parameter
Activation time program HYDRAULIC PARAMETER 05
