5.6.6 Raising Return Temperature Level
5.6.7 Solar Level (..VV..)
26
Basic load parallel shift (only
when used in cascade
mode)
0…60 K 10 K 10-3
27**
Heat circuits minimum
temperature limit
5 °C...BT
min
(only if start up release is separated-
Parameter 02 = 3)
36 °C 8-2
28**
Switching difference
Minimum temperature limit
heating circuits
2 K...20 K (only if start up release is separated-
Parameter 02 = 3)
4 K 8-2
29 H-GEN forced discharge
Off no function
1 Into DHW tank
2 Into heating circuits
3 Discharge in buffer tank
OFF 8-18
30*
OEM maximum temperature
limit
Minimum temperature limit ... 110 °C 110 °C 8-3
31* Minimal load control OFF, 1...10 min OFF
RESET
ST-1
Reset oper. hours / starts
stage 1
SET - 8-19
RESET
ST-2
Reset oper. hours / starts
stage 2
SET - 8-19
Parameter Designation Setting range / Setting values
Factory
settings
Individual
setting
Link
01 Return flow limiting setpoint 10 ... 95 °C 20 °C 8-13
02 Switch-off differential 1 ... 20 K (only if RBP in operation) 2 K 8-13
03 Extended run time (pump) 0 ... 60 min (only if RBP in operation) 1 Min 8-13
Parameter Designation Setting range / Setting values
Factory
settings
Individual
setting
Link
01 Switch-on differential (Switch-off differential +3 K) ... 30 K 10 K 8-40
02 Switch-off differential 2 K ... (Switch-on differential -3 K) 5 K 8-40
03
Minimum run time of solar
panel pump
0 ... 60 Min 3 Min 8-40
04
Maximum temperature limit
of solar panel
70 ... 250 °C 120 °C 8-40
05
Maximum temperature limit
solar buffer
50 ... 110 °C 75 °C 8-40
Parameter Designation Setting range / Setting values
Factory
settings
Individual
setting
Link
