EbV Product documentation THETA NORM/UNIT
5-42
5.6.2 SYSTEM level
* only OEM
Parameter Designation Setting range / Setting values
Factory
settings
Individual
setting
Link
LANGUAGE Language selection
DGerman
GB English
F French
IItalian
D 5-32
TIME
PROGRAM
Number of enabled time
programs
P1 Only one time program
enabled
P1-P3 Three time programs
enabled
P1 5-32
CONTROL
MODE
Enabling of separate control
mode setting (room temp.
specific. and operat. modes)
1 Common setting for all
heating circuits
2 Separate setting for every
individual heating circuit
1 5-33
SUMMER
Limit temperature for
summer switch-off
OFF no function
10...30°C switch-off at set value
20 °C 7-3
05 System frost protection
OFF no function
-20...+10 °C frost protection at set value
3 °C 7-4
06
Heat requiring contact at
VI 1
1 Unmixed circuit
2 Mixed circuit
13 Mixed circuit
24 Domestic hot water
ALL All circuits
1
8-57
8-59
07
Heat requiring contact at
VI-2 (Type .. VV..)
Settings see parameter 06 1
08
Heat requiring contact at
VI-3 (Type .. VV..)
Settings see parameter 06 1
09 Climate zone -20..0.0°C -12 °C 7-3
10 Building type
1 light construction
2 medium construction
3 heavy construction
2 7-1
11
Time for automatic exit
(return to basic display)
OFF No automatic exit
0.5...5 min after set time automatic
return to standard display
2 Min 5-18
12
Pump and mix valve forced
operation (Anti-blocking
protection)
ON active
OFF not active
ON 7-6
13
Logical malfunction
messages
OFF no display
EIN Display active
OFF 11-6
14 Automatic Set-Function
OFF automat. sensor recognition
deactivated
ON automat. sensor recognition activated
OFF 11-1
15*
Locking code for heating
specialist
OFF (0000) no lock
ON (0001...9999) locked
1234 5-17
16* Type code Controller type according to type code table Type 6-6
18 Release cycle temperature
OFF cycle temperatures blocked
ON cycle temperatures enabled
ON 6-2
19 Frost protection mode
OFF permafrost protection according to
adjustment in parameter 05- plant
frost protection
0.5...60 min Cycle operation
OFF 7-7
21* RTC-adjustment -10 ... -1, 0, 1 ... 10 s 0 s 11-7
23 Anti-blocking for protection
OFF (0000) no lock
ON (0001...9999) locked
OFF 5-17
24
Temperature display in
°Fahrenheit
OFF display in °C and K
ON display in °F
OFF 6-6
RESET Reset to factory preset
in dependence on access code only to released
parameters
