Rotex Controller Series User Manual

EbV Product documentation THETA NORM/UNIT
5-47
5.6.8 Solid Fuel Level (..VV..)
5.6.9 Buffer Level (..VV..)
06 Solar operating mode
1 Priority mode
2 Parallel mode
3 Priority mode DHW (nominal value-
control)
4 Priority mode buffer (nominal value
control)
2 8-40
07 Inhibition heat generator
OFF, 0.5 … 24 h
(Only in priority mode - Parameter 6 = 1)
OFF 8-40
08 Sol. Prior./parallel mode
OFF, 1…30 K
(only in priority mode and act. inhibition)
OFF 8-40
09 Solar energy balance
OFF no heat balancing
1 Balance via flow calculation
2 Balance via pulse processing
OFF 8-40
RESET SOLAR Reset solar energy balance
Reset: SET by pushing the rotary push-button
(only if solar heat balance is enabled)
- 8-40
11 Volume flow
0.0 ... 30 l/min or l/impulse (only if solar heat
balance is enabled)
0.0 l/
Min
8-40
12 Fluid density
0.8 ... 1,2 kg/l
(only if solar heat balance is enabled)
1.05
kg/l
8-40
13 Fluid heat capacity
2.0 ... 5.0 KJ/kgK
(only if solar heat balance is enabled)
3.6 KJ/
kgK
8-40
14 Final switch-off temperature OFF, 90… 210 °C 150°C 8-40
15 Test cycle solar load switch 1 … 60 Min 10 Min 8-40
16 Switch-over temperature 50...110°C 75°C 8-40
Parameter Designation Setting range / Setting values
Factory
settings
Individual
setting
Link
01 Minimum temperature 20 ... 80 °C 60 °C 8-51
02 Maximum temperature 30 ... 100 °C 90 °C 8-51
03 Switch-on differential (Switch-off differential +3K) ... 20 K 10 K 8-51
04 Switch-off differential 2 K ... (Switch-on differential -3K) 5 K 8-51
05 Inhibition heat generator OFF, 2...180 min OFF 8-51
Parameter Designation Setting range / Setting values
Factory
settings
Individual
setting
Link
01 Minimum temperature buffer 5 °C ... Maximum temperature buffer 20 °C 8-43
02
Maximum temperature
buffer
Minimum temperature buffer ... 95 °C 80 °C 8-43
03 Temperature excess H-GEN -10 ... 50 K 8 K 8-43
04 Switching differential 1 ... 20 K 2 K 8-43
05 Forced heat dissipation
OFF
1 Into DHW tank
2 Into heating circuits
OFF 8-43
Parameter Designation Setting range / Setting values
Factory
settings
Individual
setting
Link
