Rotex Controller Series User Manual

EbV Product documentation THETA NORM/UNIT
5-49
5.6.12 RELAY TEST Level
5.6.13 ALARM Level
* only OEM
5.6.14 Level SENSOR ADJ.
Parameter Designation Setting range / Setting values
Factory
settings
Individual
setting
Link
01 Heat generator test
Different relay sequence according to type of boiler
(one or tow level)
OFF 11-3
02
Direct heating circuit pump
test
OFF-ON-OFF -... OFF 11-3
03 Mixing circuit pump 1 test OFF-ON-OFF -... OFF 11-3
04 Mixer actuator 1 test STOP-OPEN-STOP-CLOSE-STOP… STOP 11-3
05 Mixing circuit pump 2 test OFF-ON-OFF -... OFF 11-3
06 Mixer actuator 2 test STOP-OPEN-STOP-CLOSE-STOP… STOP 11-3
07
DHW charging
pump test
OFF-ON-OFF -... OFF 11-3
08 Variable output 1 test OFF-ON-OFF -... OFF 11-3
09 Variable output 2 test OFF-ON-OFF -... OFF 11-3
Parameter Designation Setting range / Setting values
Factory
settings
Individual
setting
Link
01 Malfunction message #1 Last malfunction message 11-4
02 Malfunction message #2 Next to last malfunction message 11-4
03 Malfunction message #3 Third to last malfunction message 11-4
04 Malfunction message #4 Fourth to last malfunction message 11-4
05 Malfunction message #5 Fifth to last malfunction message 11-4
PARA RESET*
Resets the error message
memory
11-4
Parameter Designation Setting range / Setting values
Factory
settings
Individual
setting
Link
01 Outdoor sensor - 5 K ... + 5 K 11-7
02 Heat generator sensor - 5 K ... + 5 K 11-7
03 Domestic hot water sensor - 5 K ... + 5 K 11-7
04 Flow sensor mixing circuit 1 - 5 K ... + 5 K 11-7
05 Flow sensor mixing circuit 2 - 5 K ... + 5 K 11-7
06
Solar panel
sensor
- 5 K ... + 5 K 11-7
07 Solar buffer sensor - 5 K ... + 5 K 11-7
08
Variable
input 1
- 5 K ... + 5 K 11-7
09
Variable
input 2
- 5 K ... + 5 K 11-7
10
Variable
input 3
- 5 K ... + 5 K 11-7
