Rotex Controller Series User Manual

EbV Product documentation THETA NORM/UNIT
5-40
5.6 Parameter Settings
5.6.1 HYDRAULIC Level
Parameter Designation Setting range / Setting values
Factory
settings
Individual
setting
Link
01 Hydraulic diagram 0000, .... 9999 0
02
DHW charging pump output
(Type ..B..)
OFF No function
1 DHW charging pump
4 DHW circulation pump
5 DHW electrical heating element
1
8-34
8-39
8-40
03
Mixing circuit 1 (MC1) output
(Type ..3..)
OFF No function
2 Direct circuit (outdoor temp. contr.)
3 Mixed circuit (outdoor temp. contr.)
6 Constant temp. contr.
7 Fixed value contr.
8 Raising return temp.
3
8-19
8-19
8-56
8-56
8-13
04
Mixing circuit 2 (MC1) output
(Type ..3.3..)
Setting range and assignment see parameter 03 3
05 Direct circuit 1 (HC) output
OFF No function
2 Direct circuit pump
4 DHW circulation pump
5 DHW electrical heating element
6 Constant control
10 Feed pump
11 Boiler circuit pump 1
12 Boiler circuit pump 2
13 Alarm output
14 Timer
15 Solar charging pump (..VV..)
21 Parall. H-GEN-clearance (..VV..)
27 Hydraulic buffer release (..VV..)
2
8-19
8-39
8-40
8-56
8-39
8-12
8-12
8-58
8-58
8-40
8-13
8-55
06
Variable output 1
(Type ..VV..)
OFF No function
4 DHW circulation pump
5 DHW electrical heating element
9 Boiler bypass pump
10 Feed pump
11 Boiler circuit pump 1
12 Boiler circuit pump 2
13 Alarm output
15 Solar charging pump
16 Buffer charging pump
17 Solid fuel boiler pump
19 Solar changeover charging valve
20 Solar forced heat removal
21 Parall. H-GEN-clearance (..VV..)
26 Priority pump
27 Hydraulic buffer release (..VV..)
OFF
8-39
8-40
8-13
8-39
8-12
8-12
8-58
8-40
8-43
8-51
8-53
8-54
8-13
8-12
8-55
07
Variable output 2
(Type ..VV..)
Setting range and assignment see parameter 06 OFF
08 Variable input 1
OFF No function
1 Outdoor sensor 2
2 Heat generator sensor 2
3 DHW tank sensor 2
4 Buffer sensor 2
5 Demand contact
6 External alarm input
9 Return flow sensor
10 External blocking (heat generator)
11 External switching modem
12 External information
13 Common flow sensor
14 Solar panel return sensor
16 Flue gas sensor
18 Solid fuel buffer sensor
19 Buffer sensor 1
27 Minimum value intrusion
OFF
7-1
8-15
8-34
8-43
8-57
8-58
8-13
8-16
8-59
8-60
8-16
8-40
8-10
8-51
8-43
