EbV Product documentation THETA NORM/UNIT
11-3
11.3 Relay / Function Test
Function: Depending on the controller version various outputs can be tested. This is not only a
relay test, but a function test by means of which the hydraulic components are tested.
The partially compulsory sequence of the switching procedures is considered.
After selecting the test function the relevant relays can be switched one by one by
pressing the rotary pushbutton in the specified switching sequence.
Heat generator: Heat Generator Test
a Single stage heat generator
(Level heat generator Parameter 1 = 1)
Switching sequence: OFF, ON, OFF...
b 2-stage heat generator
(Level heat generator Parameter 1 = 2)
Switching sequence: OFF, STAGE 1, STAGE 1+2, STAGE 1, OFF.....
c 2x1-stage heat generator
(Level heat generator Parameter 1 = 3)
Switching sequence: OFF, HG 1, HG 1+2, HG 2, OFF.....
d modulating mode
(Level heat generator Parameter 1 = 4)
Switching sequence: OFF, ON, OPEN, STOP, CLOSE, OFF...
Pumps / VOs: Test Pumps
(Unmixed circuit pump, mixed circuit pump, DHW loading pump, variable out-put 1,
variable output 2)
Switching sequence: OFF, ON, OFF,...
MIMO: Test Actuator Mixed Circuit
Switching sequence: STOP, OPEN, STOP, CLOSED; STOP....
Operation:
Note on operation Key / parameter tree Parameter
Relay test heat generator RELAY TEST HEAT GENER.
Relay test unmixed circuit pump RELAY TEST OUTPUT HC-P
Relay test mixed circuit pump 1 RELAY TEST OUTPUT MCP 1
Relay test actuator mixing valve 1 RELAY TEST ACTUATOR MC-1
Relay test mixed circuit pump 2 RELAY TEST OUTPUT MCP-2
Relay test actuator mixing valve 2 RELAY TEST ACTUATOR MC-2
Relay test DHW charging pump RELAY TEST OUTPUT DHW
Relay test variable output 1 RELAY TEST OUTPUT VO-1
Relay test variable output 2 RELAY TEST OUTPUT VO-2
