34  April 2015  IMO_374_EN_v1 Roto Patio Fold Subject to change.
Hardware overview
Parts list enhanced threshold
PB 48 Fin-Seal brush seal
Description Surface-nish PQ Material no.
Brush seal, 10mm Grey 60m 601080
Cut by the metre Grey variable 602186
Brush seal, 17 mm Grey 40m 604872
Cut by the metre Grey variable 604873
Optional
27. 4
15
6
10
Weather profile strip I
Description Length Surface-nish PQ Material no.
Weather prole strip I 6m E6/C-0 60m 543515
1.18m E6/C-0 25pcs 543518
Cut by the metre E6/C-0 variable 625768
26.5
14
3
11
Weather profile strip II
Description Length Surface-nish PQ Material no.
Weather prole strip II 6m E6/C-0 60m 543497
1.18m E6/C-0 25pcs 543500
Cut by the metre E6/C-0 variable 625769
26.5
14
3
11
Weather profile strip III
Description Length Surface-nish PQ Material no.
Weather prole strip III 6m E6/C-0 60m 543506
1.18m E6/C-0 25pcs 543509
Cut by the metre E6/C-0 variable 625772
27. 4
15
6
10
Weather profile strip IV
Description Length Surface-nish PQ Material no.
Weather prole strip IV 6m E6/C-0 60m 543486
1.18m E6/C-0 25pcs 543489
Cut by the metre E6/C-0 variable 625770
End cap for weather profile strip (pair)
Description Surface-nish PQ Material no.
End cap for weather prole strip Grey 5 0 P. 540403
NOTE!
Further hardware parts for the enhanced
threshold can be found in the Door catalogue
CTL_8_EN.
