Roto Patio Fold - Installing the sash retaining device

Subject to change. Roto Patio Fold IMO_374_EN_v1  April 2015  71
Installation
Accessories
Installing the sash retaining device
45
Cam of
sash
retaining
device
Bush of sash
retaining
device
SW/2-30 SW/2-30
Adapt the locating height to the profile
1.
Determine the position according to the drawing.
2.
Predrill Ø 3.5mm.
3.
Screw-fix the sash retaining device with countersunk
screws Ø5mm.
A
B
C As
B B
CC
D
DIAGRAM 871
DIAGRAM 330
DIAGRAM 321
A E As
B
A
B
C F
DIAGRAM 431
A
B
C As
D
DIAGRAM 541 DIAGRAM 550DIAGRAM 532
A
B
C As
B
E A
B
C FC
B
A
B
C As
Bs
Es
DIAGRAM 743 DIAGRAM 752 DIAGRAM 761 DIAGRAM 770
A
B
C AsE
B Bs
Cs A
B
C
B
C As
Bs
Es A
B
C As
B B
EC A
B
C FC
B B
C
DIAGRAM 651DIAGRAM 633
A
B
C As
B D
CA
B
C As
D Bs
Cs
45
