Roto Patio Fold - Mounting support bracket for bottom roller track

46  April 2015  IMO_374_EN_v1 Roto Patio Fold Subject to change.
Installation
Sash
Mounting support bracket for bottom roller track
5
18.5
26
6
19.5
17
22
19
20.5
13
10
9.5
30.5
30
14.5
5
5
5
6
6
15.5
5
30.5
26
27.5
6
31.5
29
34
31
32.5
5
6
5
5
6
13
10
9.5
30.5
30
14.5
NOTE!
 Observe the profile-specific installation
instructions , because some aluminium
profile systems must be drilled in timber
position .
 Seal the holes for the outer support brackets
with suitable sealing compound to prevent
the ingress of water.
