38 April 2015 IMO_374_EN_v1 Roto Patio Fold Subject to change.
Drilling jigs
Drilling jig (hinges and support bracket) 643365
Drilling jig (roller tracks and guide tracks) 314417
Drilling jig (sash stop) 469831
Tools
Allen key 208609
Adjusting key 258191
Pin extractor handle 740068
used to insert and/or remove stay-bearing pins
Replacement blade for pin extractor handle 230765
