36 April 2015 IMO_374_EN_v1 Roto Patio Fold Subject to change.
Prole Frame hinge-bearing / Hinge Sash hinge-bearing / Hinge Drawing no. Adapter prole
Eifel TB (see page 33)
Universal threshold
bracket (see page 34)
Brush prole
holder
Brush seal
Frame hinge-bearing/
Hinge
Packer Sash hinge
outside
Sash hinge
inside
Pin length
Support bracket
Packer
Support bracket
10 mm 17 mm
Cortizo COR 60 07/50, pin 25 1 20/40, pin 25 30/40, pin 25 30 mm 6+3mm S14A560-000 548528 70 - 80 mm 640408 601080 604872
Extragusa V-8000 07/50 – 20/40, pin 25 30/40, pin 25 40 mm 6+3mm S14A475-000 548528 68 mm 640408 601080 604872
Feal Termo 65 7/50, pin 25 1 20/40, pin 40 30/40, pin 25 30 mm 6+3mm S15A133-000 548528 68 mm – – –
Feal Z50 Alu 7/50, pin 25 1 20/40, pin 40 30/40, pin 25 30 mm 6+3mm S15A114-000 548528 68 mm – – –
Sykon Serie 75 10/50, pin 25 – 20/40, pin 25 30/40, pin 25 30 mm 6+3mm S14A611-000 548528 70 - 80mm 640408 601080 604872
Yawal 7/50, pin 25 2 20/40, pin 25 30/40, pin 25 30 mm 6+3mm S15A091-000 548528 70 mm 640408 601080 604872
Hardware overview
Profile systems
NOTE!
Further profile assessment upon request.
