Opening Fold&Slide doors
The following symbols show the different handle positions and the resulting
sash positions of windows and balcony doors.
Handle position Sash position Symbol Meaning
Closed position of the sash
Turn and fold position of the sash
Opened tilt position of the sash
Malpositioning of the sash
