Quick Check
28
Ocean 2014 User's Manual
2014-06-02/3.2A
compression paddle:
The following meter settings are available in Quick Start:
Add a delay after the detection of trig before measurement of kVp starts. This will
delay the kVp measurement, it doesn't affect dose, mAs or time measurements.
This is the time the meter waits after trig off before it assumes that the exposure
is finished. The post delay must be set to a time longer than any dead time in the
radiation.
Current kV range. You need to change this only for radiography/fluoroscopy, for
mammography, dental and CT you only have one range.
Available calibrations for the internal (kVp and exposure) used. See table below
that describes usage of the different calibrations.
Sensitivity setting for the kVp detector (internal detector).
Hi = High sensitivity - for low dose rate
Lo = Low sensitivity - for high dose rate
Sensitivity setting for the dose and total filtration measurement (internal detector).
Hi = High sensitivity - for low dose rate
Lo = Low sensitivity - for high dose rate
Sensitivity setting for the external probe
Hi = High sensitivity - for low signals
Lo = Low sensitivity - for high signals
Calibration for the external probe
You can select between Normal, Timed or Free run
Normal =use this measuring mode for exposures and fluoroscopy
Timed = meter measures during a time you specify
Free run = meter measures continuously without use of any trig levels
(for more information see table below)
Measurement
time
(Timed mode
only)
Measuring time when Timed mode is used.
