Russound MCA-C3 User and Installation Manual
TECHNICAL SPECIFICATIONS
MCA-C3 Multizone Controller
Dimensions: 17"W x 3.5"H x 17.2"D (43.2 x 9 x 43.6 cm)
Weight: 28.8 lbs. (13.1 kg)
Power Supply: 120 or 240 VAC
Fuse Rating: 100-120V/T3.15A 250V US and Canada
220-240V/T1.25A 250V Europe
Power Consumption: 400 watts maximum
Standby Power Consumption: <1.0 watt
Frequency Response: 20Hz-20kHz +/- 1 dB at 1W output into 8 ohms
Watts per channel: 20W RMS into 8 ohms
Total Harmonic Distortion: <0.10%
Signal to Noise Ratio: 93 dB unweighted, 96 dB A-weighted
Audio Source Inputs: 6 (including internal tuner)
Audio Zone Outputs: 6 Speaker Level (Zones 1-6)
(2 Line Level xed or variable)
Trigger Outputs: 6 12VDC 100mA, 1 Home theater
Trigger Inputs: 1 Home Theater 12VDC max
1 Page 12VDC max
Speaker connection: 6 detachable 4 pole connectors
Keypad ports: 6 RJ45 T568A standard
IR Outputs: 6 routed, 1 common
Communication ports: Front- 1 USB 2.0/1.1
Rear- 1 Serial RS232, 19.2 kHz baud rate
1 Ethernet RJ45, 10/100 Base T
2 RJ45 RNET Links In/Out
Frequency Range: AM 530 - 1710 kHz
FM 87.7 - 107.9 MHz
Antenna impedance AM: 300 Ohm balanced
Impedance FM: 75 Ohm unbalanced
Sensitivity: AM: @20 dB S/N 55 dBu
FM: @30 dB S/N 6 dB max 12 dBu
Image rejection: AM: 33 dB FM: 80dB
S/N ratio: AM: 45dB FM: 60 dB
MDK-C5 Keypad
Power requirements: 275mA @ 12VDC MAX
CAT-5e connection: RJ45 (T568A standard)
Display: 70 mm W x 35 mm H
high resolution LCD
Controls: Eleven backlit hard buttons
Wall surface dimensions: 4.5"W x 4.5"H
(11.43 x 11.43 cm)
Inside box dimensions: 3.5"W x 1.5"D x 2.75"H
(8.9 x 3.8 x 6.9 cm)
Weight: 1 lbs. (0.45 kg)
The MCA-C3 Controller meets EU Standby Power Requirements
