SAIC MG 6 - Battery Top Fuse Box

To Next Page

To Previous Page

EmergencyInformation

BatteryT opFuseBox

F 1

F 2

F L 4 F L 3 F L 2 F L 1

CheckingorRenewingFuses

1T urnofftheignitionswitchandallelectrical

equipment.Disconnectthebatterycable.

2Pressthebuckle(seeillustration)toremovethe

cover .

3Checkifthereisanyblownfuse.

4Forablownfuse,replaceitwithsamerating.

FuseSpecication

Code

RatingFunction

FL1

30AEPBECU

FL230AEPBECU

FL360AAuxiliaryFuses1,2,3,4,5

FL450ARelay-SecondaryAirPump

Code

RatingFunction

5AEBS
